Characteristics:

2 minutes of continuous output at 1000A

Flexible output control, such as manual, ramp, etc.

Independent auxiliary DC power supply

Typical CT test functions are also included

Main specifications

AC current (I1)

Range: 1000A / 7000VA

Accuracy 0.5%

Operating time 120s at 1000A

AC voltage (U1)

250V / 750VA range

Accuracy 0.5%

Continuous use time

DC voltage (Udc)

300V / 750W range

Accuracy 0.5%

20-240V auxiliary DC power supply

0 to 600 V ac / dc voltmeter

Ammeter 0 to 6A ac / dc

Binary input 2 Binary output 1

Dimension 260 * 330 * 500 mm

Weight 30 kg
