Ponovo TD2000 DC power source 0-2000A or TD4000



TD series test equipment consists of a control unit and a high current DC output unit.



Also available TD4000 0-4000A output



TD2000 test equipment produces 0-2000A DC current with 0.1% accuracy



This equipment is used in HVDC converter stations and tests the characteristics of the DC current transformer.



Manual and automatic test by software



Output DC current waveform by USB port

High multi-current connector for busbars

Easy panel control with LCD display and rotary encoder

Ordering info / .pdf document
Ordering info / .pdf document



Main specifications TD2000A



Output range 0-2000A

Max output voltage 5V

DC current output accuracy 0.1%

Display accuracy (rd) 0.2%

Display accuracy (rg) 0.05%

Binary input 2 Binary output



Input power

3 × 380Vac, 22kVA



Weight 80 kg
